Mobile Trolley
Mobile Trolley is designed for transporting sterile products under
ISO Class 5 (Class 100) particle free work area for storing sterile products to
meet storage needs while making a positive contribution to maintaining the cleanliness
of your controlled cleanroom environment.
The work area is continuously supplied with positive pressure HEPA filtered recirculated
vertical / horizontal air flow. Our range of mobile trolley cabinet
is available in various specifications as per the client’s requirements.
Mobile Trolleyis with a variety of standard dimensions also our
Mobile Trolley can be custom engineered to any size. Mobile Trolley is available
in powder coated Mild Steel, SS 304 / 316 / 316L or a combination of both.
Standard Model Available :
|
Model No.
|
Work Area (mm)
|
Airflow Velocity
(Down flow)
|
Air Cleanliness
|
Air Flow
|
|
MT-24-24-24
|
610 X 610 X 610
|
0.45±0.05mps/
|
ISO Class 5 (ISO 14644-1:1999 (E)) /
|
Horizontal –
Recirculatory
|
|
MT-24-24-36
|
610 X 610 X 915
|
90(fpm)
|
Class 100 (U.S. FED STD 209 E)
|
|
Technical Specification :
|
Supply filter :
|
Imported Minipleat HEPA filter with hot melt technology, which conforms to EU-14
Grade at supply position with an efficiency rating better than 99.999% down to 0.3µ.
|
Return
Air Pre-filter :
|
Return Air Pre-filter are made from non-woven synthetic with HDPE mesh; conforms
to EU 6 grade, with an efficiency rating better than 95% down to 5µ.
|
Fresh
Air Filter :
|
Fresh Air Pre-filter are made from non-woven synthetic with HDPE mesh; conforms
to EU 4 Grade, with an efficiency rating better than 90% down to 10µ.
|
Motor
Alower Assembly :
|
Motor blower designed of statically and dynamically balanced for supply of sufficient
capacity and static pressure to take care of airflow requirement for entire life
of HEPA.
|
|
Differential Pressure Gauge :
|
Dwyer Make Magnehelic Gauge (0 -25 mm: 1 No.) to monitor pressure drop across HEPA.
|
|
Door :
|
SS 304 double walled door construction with flush glass view panels with SS handles
and SS hinges.
|
|
Interlocking :
|
Electro-Magnetic interlocking arrangement to put-off UV Light if either side door
opens.
|
|
Shelves :
|
SS 304 hanging arrangement (or) removable type shelves
|
|
Temperature Control :
|
Heater with thermostat for control of temperature in cabinet
|
|
Battery back-up :
|
Battery back-up with inverter for 30 mins
|
|
Castrol wheel :
|
PU coated lockable castor wheels
|
|
ON/OFF Switches :
|
SS ON/OFF switches for motor & lights
|
|
Switch Socket :
|
6/15 amp single-phase switch socket use for external equipment
|
|
DOP Port :
|
DOP test port at upstream of HEPA filter to personnel for carrying out the HEPA
filter integrity test.
|
|
Handle :
|
SS 304 Handle for mobility
|
|
Electrical Supply :
|
230V AC 1- Ø 50HZ / 415V AC 3-Ø 50HZ
|
|
Noise Level :
|
Less than 67 dB on scale ‘A’ when ambient is not greater than 55 dB on scale ‘A’
|
|
Vibration Level :
|
Minimum
|
Optional Accessories :
U.V. Light with Hour Meter used for bacteria/virus killing & interlocking arrangement
to put off UV Light if either side door opens.
Electro-Magnetic / Mechanical Interlocking
Audio visual alarm indicating condition of HEPA filters
Clean down timer with operation hold indicator
VFD based control systems
Photohelicguage / Digital pressure gauge to monitor of pressure drop across filter.
Sodium vaporlamps
Flame proof fitting
